Working with carbon steel, high strength, and stainless steel, Metalstamp-Inc. provides heavy gauge stamping for a wide range of industries. Metalstamp-Inc. features 45 presses with up to a 1500 ton press rating. Metalstamp manufactures metal parts with materials ranging up to .625″ in thickness. Metalstamp specializes in progressive and multi-operational dies to accommodate your heavy gauge production needs. With a 45-year history of providing heavy gauge stampings, we are a leader in this metal fabrication process. To learn more about our stamping services, please contact Metalstamp-Inc.
Specifications for Heavy Gauge Stamping Capabilities
| General Capabilities | Production Contract Manufacturing Prototype |
Custom Bulk |
|---|---|---|
| Production Method | Progressive Die Single Hit |
Transfer |
| Production Capabilities | High Strength Heavy Gauge |
First Operation Blanks |
| Stamping Features | Blanking Deep Draw Countersunk Coining |
Embossed Shape Critical In Die Fastener Extrusions |
| Press Range – 45 Presses | 100 tons to 1500 tons | |
| Part Length | Up to 36 in | |
| Part Width | Up to 72 in | |
| Part Material Thickness | 0.020 in to .625 in | |
| Tolerance | ‘-+ 0.002 in | |
| Production Volume | High Volume Large Run Long Run Large Scale Production |
Prototype to Production Low Volume Small Run |
| Materials | Carbon Steel High Strength Steel Low Carbon Steel Galvanealed Steel |
Stainless Steel Aluminum Coated Steel |
| Industry Standards | ISO 9001:2015 | |
| Additional Services Provided | Assembly Washing Deburring Coating Heat Treating |
Plating Tapping Welding Design Consulting |
| Industry Focus | Recreational Vehicles Agricultural Transportation Consumer Products Bracket Market Trailer |
Automotive Appliances Braking Systems Mining Furniture |
| File Formats | AutoCAD (DWG,DWZ) IGES – Initial Graphics Exchange Specification ANSI file format |
